FOXcrystal恒溫晶振產品特性
　　2014年2月18日,美國福克斯晶振公司攜手全球領先變頻控制解決方案供應商IDT晶振公司共同合作開發出低功耗,低電壓,低電平,低抖動FTP302AH晶振,一款表面式貼片OCXO恒溫晶振.其尺寸僅為14.3毫米*9.3毫米*6.7毫米,功耗僅為0.6W(最大值).新款貼片式OCXO低功率HCMOS振蕩器可在寬溫范圍內提供超高的穩定特性.
　　新型SMD HCMOS OCXO集成了Stratum 3時鐘，可提高時序性能。當其時序?qū)傩耘c緊湊尺寸相結合時，低功耗振蕩器可用于越來越多的需要更小，更密集，但可靠性更高的電子設備的應用中。其中包括通信，數據傳輸和測試測量行業中的路由器，網關，基站和交換平臺。
　　在5MHz至40MHz的頻率范圍內以及-40°C至+ 85°C的擴展工作溫度下，F(xiàn)TP301AH的穩定性低至±50 ppb。采用業界標準尺寸，可用簡單的磁帶和卷軸配置，新型OCXO可輕松并入自動化生產線，以節省設計成本和裝配時間。
　　OCXO晶振在前30天每天最多提供最大值±5 ppb的短期老化，對所有影響提供±4 ppm的長期提前老化。內部加熱器和較小的封裝有助于快速預熱時間，以確保石英晶體振蕩器快速達到就緒模式并具有準確的穩定性。
技術規格：
•典型頻率穩定度：±100 ppb，可提供±50 ppb
•頻率范圍：5 MHz至40 MHz
•標準電源電壓：3.3 V，5.0 V可用
•典型輸出負載：15 pF，可用SineWave
•快速預熱時間至±100 ppb：5分鐘
•最大工作功率：25°C時為0.6 W.
•重量：5.4克

　　FOXcrystal constant temperature crystal product features

On February 18th, 2014, the United States Fox Crystal Corporation and IDT Crystal Corporation, a leading global supplier of variable frequency control solutions, jointly developed a low-power, low-voltage, low-level, low-pull FTP 302AH crystal oscillator, a surface-mount chip OCXO. Constant temperature crystal. Its size is only 14.3 mm * 9.3 mm * 6.7 mm, power consumption is only 0.6W (maximum). The new chip OCXO low power HCMOS oscillator can provide high stability over a wide temperature range.

　　The new SMD HCMOS OCXO incorporates a Stratum 3 clock for enhanced timing performance. When its timing attributes are coupled with its compact size, the low power oscillator can be used in a growing number of applications that require smaller,more dense, yet highly reliable, electronics. These include routers, gateways, base stations and switching platforms as found in the communications, data transmission and test and measurement industries.
　　Stability of the FTP301AH is as low as ±50 ppb over a frequency range of 5 MHz to 40MHz and an extended operating temperature of -40°C to +85°C. Using an industry standard footprint and available in a simple tape and reel configuration, the new OCXO is easily incorporated into automated production lines to save design costs and assembly time.
　　The OCXO provides a short term aging of only ±5 ppb maximum per day for the first 30 days and ±4 ppm long term for all effects. The internal heater and smaller packaging facilitates a quick warm up time to ensure the oscillator quickly achieves ready mode with accurate stabilities.
Technical Specifications:
• Typical frequency stability: ±100 ppb, with ±50 ppb available
• Frequency range: 5 MHz to 40 MHz
• Standard supply voltage: 3.3 V, with 5.0 V available
• Typical output load: 15 pF, with SineWave available
• Fast warm up time to ±100 ppb: 5 minutes
• Maximum operating power: 0.6 W at 25°C
• Weight: 5.4 g
